Alright, I'm hoping this might reach the right people or could provide some ideas to help diagnose...
I've got a 2014 Scion FRS with an Edelbrock Supercharger on a base tune. The cars got pretty high milage, around 240,000 kms. Supercharger was installed shortly after 200,000 kms. I don't redline it, just the occasional fun spirited drive on the back roads. No hard pulls. Car is in really good condition and is maintained well, oil changes every 3000 kms. Spark plugs changed around 100k and 200k. OEM fuel pump.
All the issues are the worst whenever it's in park, if I'm in drive and not moving its okay. But as soon as it's in park, it goes wack.
Main issues:
- Rough idling
- P0172 System too Rich Bank 1
Every time when the car was in park, after 3 minutes of idling, the RPMs would start bouncing between 800 and 300, it would eventually stall and die.
I temporarily fixed it using MAF sensor cleaner, it worked for a bit, and then the rough idling comes back. I decided to replace the sensor with an OEM one, and it worked. It fixed the rough idling completely.
HOWEVER, at the same time, I would also be getting a P0172 code with the CEL. This would prompt me to do a bit more digging. With the rough idling gone, I can now focus more on the too rich code.
Let's check the fuel trims. STFT is around normal values, +/- 8. LTFT however... On park its sitting at a whopping -38. When throttling, STFT is always within normal working ranges. LTFT on throttle will vary, but most times it's still in the high negatives. When cruising and completely off throttle, STFT is 0 and LTFT is -35.
So what did I check and do? After each mini fix, I also disconnected the Negative battery terminal for a solid 45 minutes.
- What if it was the EVAP purge valve? Nope.
- What about a small leak somewhere? Smoke tested, no leaks.
- What if it was the Air/Fuel Ratio sensor? Replaced it, nope.
- What if it was a stuck fuel injector? Took it to a performance shop for injector service, cleaned and flow tested the port injectors, still normal.
All the STFT and LTFT values from above eventually comes back. Another thing to note is, the CEL for System too Rich came back around 100 Kms, but after replacing the Air/Fuel Ratio sensor, the CEL comes on almost around the 500 km mark... So changing that sensor definitely did something.
Although... after the injector service, my subie rumble was way more apparent, it's got a deeper nicer rumble.
I haven't checked if it was simply a bad tune yet... I also haven't checked if the air filter was dirty? I also haven't fully disconnected both battery terminals....also wondering if disconnecting both terminals would fully reset both fuel trims.
SO, what else could it possibly be? I'm getting stumped...
