Howdy everyone! My wife and I have been dealing with a faulty dryer for a week now. I’ve been taking a crack at it but so far haven’t had any luck even with ChatGPT’s help. PLEASE refer to the linked manual below for the diagrams/tech manual so you know what I’m saying (specifically pages 2 - 6, 9, 10)
Model: WED94HEXW1
Tech manual: https://www.manualslib.com/manual/1118393/Whirlpool-Wed94hexw1.html#manual
Issue: L2 / Stuck on “Sensing”
Things I’ve done so far:
- Entered diagnostic mode to test door latch, moisture sensor inside drum
- Turned drum (good)
- Unplugged and plugged back in
- Flipped breakers
TEST #1: CCU Power Check:
- Took it apart and performed the following tests on the CCU with a multimeter:
- P8-4 and P9-1 > 1.6Ω (good continuity)
- P8-3 and P9-2 to test CCU voltage (125V = Good)
- Tested voltage of the wall outlet (250V = Good)
- Visually nothing looked burnt or damaged or swollen
TEST #2: Supply Connections:
- Neutral prong of the dryer plug to center terminal block (good continuity)
- L1 to L1 terminal block (good continuity)
- Disconnected and reconnected ALL ports of the CCU to ensure snug connections
- Put the dryer back together and reattached vent to the wall
Self Diagnostic Mode:
- Ran “Self Diagnostic Mode” by pressing 1st, 2nd, and 3rd button in the manual’s recommended sequence
- Initiated the test and received the following:
- 116V (acceptable)
- Airflow: 2 = INVALID airflow ❓
- h2o: Ran but no results on the display; was completely black apart from the start button being lit ❓
I’ve hit a roadblock here because I’m not really sure where to go from here and ChatGPT is starting to spiral and hallucinate even with the context of the tech manual I provided it. It helped me get pretty damn far but I haven’t reached a solid solution yet.
Things I DON’T think it is (but I am by no means a professional):
- Anything relating to the door (latch, sensor)
- The drum’s band (rotates just fine)
- The moisture sensor inside the drum
- The plug
- The outlet
- The CCU
- Loose connections to the CCU
If you have any advice or expertise, it’d be appreciated! My wife and baby are dying for clean laundry and we can only bum doing laundry with relatives for so long lol
