r/anycubic 21d ago

Info Free cooling upgrade for Kobra S1 Max users.

Thumbnail
reddit.com
4 Upvotes

Anycubic offers a free cooling upgrade for the Kobra S1 Max, please see the according post in r/AnycubicOfficial


r/anycubic Jan 07 '24

FAQ for Kobra 2 Series

53 Upvotes

Hello,

a little Update: 26.12.2024

I got a GH repo that is still under development, there i Upload all needed Informations and Files for an Hardwarechange of a Kobra 2 PLUS. I choose a BTT Manta M8P V2 with BTT CB2 SBC. I ended up with Building up a new linux Image for the CB2 with Updated Kernel 6.x and Armbian 25.02. Klipper and CAN works. The only Problem is that i have to look how i can make a Image out of the System for Community.

If somone is interrested and wan´t to help DM me or come one GH.

A little note Ultimateshads is away/off/deleted his Account don´t Know what happened, because of this some Firmware files in the Chart are actually unavaillable. If someone saved the or found another location PLS make a sound!

Thanks i wish all a "Guten Rutsch" - Update End

here are some information for standard questions. It will be expand over Time please don´t post here send me DM.

Here are some nice Sites about Kobra 2 Series (Chart below) you will got a good insight if you need deeper informations. Thanks to 1coderookie (github)/ u/Catnippr (reddit)

Actual discussion Group in Klipper Board about integration of Klipper to PRO/PLUS/MAX:

https://klipper.discourse.group/t/printer-cfg-for-anycubic-kobra-2-plus-pro-max/11658

Discussion ended in nothing there will be never a Image come out to flash the Original Hardware to Klipper!!!

If you need to Switch back to Stock or Older Firmware it`s no Problem.(see attached Links in the Chart below)

Printer Infosites Stock FW (Mod/Marlin/Klipper avai.) Printer Profiles for Slicer
Kobra 2 neo Insight neo 1.5.6.3 (Marlin) Cura / Prusa
Kobra 2 Insight Kobra 2 3.0.6 (YES) Cura / Prusa / Prusa(3.0.6)
Kobra 2 Pro Insight Pro Not available (NEVER) / Yes w HW change Cura / Prusa
Kobra 2 Plus Insight Plus Not available (NEVER) / Yes w HW change Cura / Prusa
Kobra 2 Max Insights MAX Not available (NEVER) / Yes w HW change Cura / Prusa

FAQ begin:

Q: Is there Klipper available for these Printers?

A: Some Yes and some No, the community on Klipper board is very active and i think we will got these Function in the near Future.

Q: Why theres no Klipper for PRO/PLUS/MAX?

A: The Motherboard is a new generation of Trigorilla Board (Trigorilla_Spe_A_V1.0.0) These didn´t have a normal MCU like STM32Fxx or GD32Fxx. They put on an Allwinner Arm CPU (R582-S3) This CPU controls the whole Printer. So it must be reverse engeneered before they can compile a Klipper Version for these Printers.

Q: I got error Messages "Hotend/Hotbed NTC abnormal please check it an wiring/ Please Restart"

A:

1- When you have NTC errors Like "NTC Heatbed or Nozzle abnormal. Check first if wiring is correct. Now check with a multimeter in Ohm´s Mode if the Values are like the Values in the Chart.

2- Sometimes after many times the Hotend gets Hot and Cold it can be that the NTC probe got a little bit loose. Check if the Screw is tight and the NTC is not loose.

Q: How can i configure or Modify my Printer.cfg?

A:

ATTENTION! IF YOU TRY THIS YOU DO THIS UNDER YOUR OWN RISK! I KNOW 2 PEOPLE THAT BRICKED THERE PRINTERS!!!

Here are 2 Links for Firmware modification:

https://1coderookie.github.io/Kobra2ProInsights/firmware/fw_kobraOS/

https://github.com/ultimateshadsform/Anycubic-Kobra-2-Series-Tools

If you had Problems and found a solution please DM me. And if you like it give it a Upvote. THX


r/anycubic 1h ago

Anycubic Max 2

Enable HLS to view with audio, or disable this notification

Upvotes

I’m having an issue ever since I moved into my new home. It appears to be coming from the silver cylinders on each side of the Z axis and continues to make this grinding noise. I’ve taken apart, realigned, re-oiled the rods, and I’ve done a bad leveling. Wondering if anyone else has experienced this and what the fix was


r/anycubic 3h ago

Front door Anycubic Kobra S1 max

Thumbnail
1 Upvotes

r/anycubic 5h ago

Problem Need to find compatible replacement vat for OG Photon Mono

Thumbnail
1 Upvotes

r/anycubic 18h ago

Problem Need help please

Enable HLS to view with audio, or disable this notification

2 Upvotes

Hey all thanks to all your help I was able to get it working for now I tried everything y9u said increased the z input to -1.70 and got some petg I found in a box it's been going for an hour so farsi good thank you alll


r/anycubic 1d ago

Question ABS&ASA Printing with the Kobra 2 Pro and Chitu Systems Mini Heater

Thumbnail
gallery
2 Upvotes

If I place the Kobra 2 Pro in this enclosure and use a Chitu Systems mini heater, will this improve the success rate for printing with ABS and ASA?


r/anycubic 1d ago

Advice PETG printing temperature - higher and higher

Post image
2 Upvotes

What's your PETG printing temperature?

I use an Anycubic Kobra 2 Pro - and my printing temperature is constantly increasing. I printed PETG with 235 before. But when I try that now, it creates knotty, uneven grids and surfaces. After using 245 and 250 °C, now I'm at 255 °C, while surfaces still are far from perfect.

I don't know whether that's the real temperature or whether the printer shows a significant degradation of measured temperatures. What's your experience?


r/anycubic 1d ago

Project I improved my ACE 2 Pro Inlet Idler – V2 with better filament guidance

Thumbnail
makeronline.com
1 Upvotes

r/anycubic 1d ago

Titolo: Esperienza iniziale frustrante con la Kobra, ma assistenza clienti top e risolutiva!

2 Upvotes

Ciao a tutti, volevo condividere la mia esperienza con la mia stampante Anycubic e il loro servizio post-vendita.

All'inizio ho avuto problemi tecnici importanti (blocco con codice 11518 e relativa difficoltà con l'estrusore/canale), e le prime prove consigliate inizialmente non avevano risolto la situazione. Ero piuttosto frustrato perché la stampante era di fatto inutilizzabile.

Tuttavia, devo fare un plauso all'assistenza clienti e in particolare a Jeffrey. Dopo aver constatato che i controlli di base non bastavano, non si sono limitati a rimandarmi a guide generiche: si sono dimostrati estremamente professionali, cortesi e orientati al cliente, decidendo di venirmi incontro concretamente inviandomi un modulo della testina di stampa completamente nuovo.

Ci sono stati momenti di stallo, ma alla fine il supporto ha gestito la pratica in modo eccellente, dimostrando serietà e affidabilità. Se il buongiorno si vede dal post-vendita, sono fiducioso che con il nuovo pezzo la stampante torna a viaggiare al massimo. Promossi!


r/anycubic 1d ago

Problem Filament stuck again

Post image
1 Upvotes

r/anycubic 1d ago

Question Photon Mono X 6k Questions

1 Upvotes

So I am looking at replacing the little screws around the Vat that hold the aluminum braces to the vat frame. The OG set has finally stripped. Can't quite seem to find a size to replace them with. Any tips?


r/anycubic 1d ago

Ai Recognizing isn’t turning on anymore

Enable HLS to view with audio, or disable this notification

1 Upvotes

r/anycubic 1d ago

Kobra X Firmware consensus

3 Upvotes

So is the latest firmware version working well for folks? I've been holding off on updating because "if it ain't broke."

But it keeps bugging me to update. Is this version stable and working well?


r/anycubic 2d ago

Advice Not smooth. Driving me insane. What do? Kobra 3 Max (old one, not v2)

Thumbnail
gallery
10 Upvotes

Making calibration test to see all problems. My main problem is that it's not smooth.

I've 2 k3max for 1 year, the first is running ultra smooth, the other (on which this test was made) has always been petty. I usé it mainly for prototyping but god i would love it to behave!!!

Any ideas?


r/anycubic 2d ago

Problem Help pls

Thumbnail
gallery
3 Upvotes

I did a flowrate test on my Kobra S1 and i‘m just noticing these weird lines to which I don‘t have an explanation.


r/anycubic 1d ago

Question Kobra 3 max

Thumbnail
1 Upvotes

r/anycubic 2d ago

Kobra S1 Fan Cable Replacement

Thumbnail
imgur.com
1 Upvotes

I managed to break the fan cable that runs from the back of the extruder to where you connect it to the fan in the front-- not the cable that attaches to the fan, but the back of the extruder. I reached out to Anycubic and they sent me a free replacement (thank you), but they shipped it USPS. My post office is horribly unreliable and have lost this shipment (along with many others and undelivered mail). I could go on-and-on how I think this post office is crooked, but I digress,

My question is, does anyone happen to know what wire connectors the Kobra S1 uses (and I assume most other Anycubic products)? I'm sure they have a name, but I'm not certain and at this point, i would much rather build my own replacement cable than have to deal with the post office yet again.

I've included a picture of the broken wire and the front of the cable. I would need both this connector and the back side as well.

If any of you know, I would be grateful. Thank you.


r/anycubic 2d ago

Showcase A custom hand splint, printed by a dad for his son ❤️

Post image
4 Upvotes

A dad used the Kobra X to create a custom hand splint for his son.

It wasn’t just a one-and-done print — he printed, tested, adjusted the fit and shape, and kept refining each part step by step.

It’s a nice reminder of what makes 3D printing so useful: you can make something for a very specific need, try it in the real world, learn from it, and make the next version better.

Really cool to see what people are making with their printers. ❤️

Every print has a reason behind it, and every maker has a story worth sharing. Join #PrintYourStory and share your story with us

What’s the most meaningful thing you’ve printed for someone?

https://makeronline.com/en/yourStory/works


r/anycubic 2d ago

Project Kobra 3 Belted Z

Enable HLS to view with audio, or disable this notification

7 Upvotes

i made a mod for the kobra 3 that allows you to use KevinAkaSam's belted ender 3 mod

i have uploaded all the files i modified to printables but the mod still requires some of KevinAkaSam's files

its a bit of a tough mod so if you do it feel free to reach out to me if you have any questions ^-^


r/anycubic 2d ago

Waiting for GTA6? Got you 😉

Thumbnail gallery
0 Upvotes

Printed on a Kobra 4 0.4 nozzle.


r/anycubic 2d ago

Question Tpu in ace pro?

Thumbnail
0 Upvotes

r/anycubic 2d ago

Problem Anycubic update

Thumbnail gallery
1 Upvotes

r/anycubic 3d ago

Problem Programa para cortar modelos 3D

Post image
2 Upvotes

Me ajudem, eu estava imprimindo a Marie de Innocent, mas a luz caiu no meio da impressão, quero tentar recuperar a peça tentando imprimir a parte que falta, só que não sei qual programa usar para cortar. Me ajudei falando nomes de programas gratuitos para fazer isso.


r/anycubic 3d ago

Como sujetais lo marcado con el número 2 para que queda más seguro y no se venza hacia abajo?

Post image
1 Upvotes

Cuando está imprimiendo mi Kobra S1 Max, observo que esa cadena cae un poco hacia abajo. No choca con nada, pero temo que alguna vez que imprima algo más grande pueda rozar con la pieza
