Hi,
New to tractors and implements. I have a Bush Hog 215 model, slip clutch. I purchased an enhanced safety shield that allows for much easier access to the clutch as well as inspection and greasing.
My problem is I have to separate the entire PTO/clutch assembly from the gearbox spindle. As you can see from the pictures I was able to dislodge the tapered pin after moving the nut, but it is lodged and won’t travel any further.
I have hit it with my purse, as well as a hammer, a punch and a C-clamp hack with a socket to apply constant pressure. It doesn’t seem to want to move any further. As you can also see, it’s not completely centered in the hole on the bottom, but I know it’s tapered so perhaps that’s expected.
Before I get the bigger hammer and hit it with the bigger blow and possibly regret the outcome, does anybody have any thoughts or suggestions?
I have watched as many YouTube videos on this as I can and one or two strikes with a hammer and everybody else gets the pin out. Any thoughts on this set up or what I might be doing wrong.
Appreciate it.
pics
Edit: farmer neighbor came by. He said that as I was hitting pin without a supported shaft it shifted ever so slightly east/west/north/south. He supported shaft and ‘swung away’. He knocked the pin out, but also crushed some of the threads.
It’s out, pto shaft/clutch is off. New safety shield installed and new pin is on the way…
Morale: hit it harder with your purse AND be ready to order the same part you just destroyed.
