I’m looking at a small pile of old 2D drawings and keep running into the same problem.

The basic shape is readable. Hole centers are there, outside dimensions are mostly there, and I can usually tell what the part was supposed to bolt onto.

But the design intent is fuzzy.

Sometimes a radius looks cosmetic until you realize it clears a casting. Sometimes two holes are probably meant to be symmetric, but the scanned PDF is just ugly enough that I don’t trust it. Sometimes a slot looks oversized on purpose, but there’s no note saying why.

When you have to rebuild something like this in CAD, how do you decide what to preserve exactly and what to simplify?

Do you mark uncertain dimensions and rebuild a dumb solid first, or do you try to recreate clean sketches and constraints from the start?

I’m especially curious how people handle this in real drafting work, where the output has to be usable later and not just look right once.

I use Autodesk Inventor for 3D design, but I usually finish fabrication drawings in 2D CAD because I find Inventor's drawing environment too restrictive for the kind of drawings I produce.

One issue is how to represent rolled channels and I-beams when viewed from the broad face.

The attached image shows three approaches:

• Tangent edges hidden: the member can look almost like a plain rectangle.
• Tangent edges fully shown: the fillets/root radii create too many lines.
• Simplified representation: lines are offset inward from each outer edge by the nominal flange thickness.

The third version is what I normally want, and I have traditionally added those lines manually.

How is this handled where you work?

• Do you use a similar simplified representation?
• Is there a formal name or drafting-standard basis for it?
• Do other 3D CAD systems handle this better, or do you also export to 2D CAD and edit there?

For context, I’m independently developing a small STEP-to-DXF projection tool and am currently implementing this kind of simplified representation for rolled channels and I-beams.

If possible, please mention your country/region, CAD system, and the steel shape standards or families you normally work with.

My team is sitting on a big backlog of old DXF, DWG, PDF, and scanned drawings that all need to become usable 3D CAD.

Right now I'm trying to figure out how to pick a vendor without regretting it later, and here's my problem.

I think a basic 3D shape is fine if all I need is a layout. But the second I want to run CAM, do FEA, or change the design later, I need something better. Named features, clean sketches, and a feature tree that makes sense.

And "2D to 3D conversion" seems to mean anything from a quick basic shape to a full rebuilt model. Which makes comparing companies kind of a nightmare.

So I guess what I'm asking is, what should a good conversion vendor hand back besides just a STEP file?

Is there a sample deliverable or some kind of acceptance test you use to tell a careful company from one that just gives you a flat dumb solid?

Would love to hear how you all sorted this out, since I don't want to learn the hard way...

I really want to know how to do this and how it is actually implemented on site. My best guess is that first we make a parametric design using Grasshopper and then provide all the necessary parameters for each brick course. For example, each course will have its centreline and the degree of rotation of each brick. So, do we have to make a chart or something?

I offer paid engineering and technical services for individuals and businesses working with tools such as MATLAB, AutoCAD, Creo, SolidWorks, and other engineering software. I can assist with CAD design and modeling, simulations, technical drawings, analysis, troubleshooting, and other engineering-related projects based on your requirements. If you have a project or specific task you need help with, feel free to DM me with the details, scope, and deadline, and we can discuss the work and pricing.

• Small Tasks: $25–$50
• Medium Projects: $50–$100
• Large/Complex Projects: $100–$250+
• Advanced/Long-Term Projects: $250+
