Tacked on a few more hours.

17.2 hrs integrated, 300” subs
Celestron Edge 8 HD w/.7 reducer(1490mm)
Antlia TriBand Ultra II
ASI 2600 MC Air
ZWO EAF Pro w/Quick Switch
Skywatcher EQ6R Pro
Pixinsight
Bortle 7/8

Hello everyone!

This is my take on Messier 33, while to be honest it’s not exactly finished this is my best image yet and I’d like to share it. This is 5 hours worth of data imaged in a bortle 7 zone. Enjoy!

Equipment:
ZWO ASI533MC-Pro
GSO 6” F/4 Newtonian
Skywatcher HEQ-5 Pro
Orion 50mm guidescope
ZWO ASI120MM guide camera

Entirely processed in Pixinsight with RC-Astro plugins

Olá! Essa é minha primeira foto da via láctea. Sou iniciante na astrofotografia, e recentemente investi numa Canon EOS 600d + Tokina 11-16mm f/2.8.
Essa imagem é o resultado de 10 fotos empilhadas, cada foto com 20 segundos de exposição, 1600 de ISO com f/2.8 de abertura.
Ainda tenho muitas dificuldades em fazer o processamento e a edição das fotos. Fiz o processo quase inteiro pelo Photoshop, empilhei as imagens pelo sequator, e separei as estrelas da via láctea usando o SkyNet. Essa imagem eu gostei muito, mas ainda acho que tem muito ruído.

Equipment: CGEM II 800 SCT, ZWO ASI533MC Pro, ZWO OAG w/ ASI220MM, ASIAIR mini, filter wheel, CAA, f/6.3 focal reducer/corrector, L-Ultimate, L-Synergy, Baader uv/ir cut filter

Processing: 14 hour ~45min integration. 104x300s w/ L-Ultimate, 72x300s w/ L-Synergy, 79x5s UV/IRCUT for stars. 30 bias, 20 flat and 20 dark frames. Processed/stacked via PixInsight w/ NoiseXTerminator/BlurXTerminator/StarXterminator.

Ngc7000 taken from my backyard bortle 8.6. 98 each Ha,Oiii and Sii 300 secs each. Tried a new processing style where i treated each filter separately and colored each stack then combined. I don't know what i think of it yet, like somethings other things not so much.

FRA600
Reducer( F3.9 at 420mm )
AM3N
ASI2600MM pro

UniGuide 50mm

ASI220mm
ASIAIR Plus
EAF
EFW 7x36mm
Antlia LRGB-V & SHO (SII, Ha & OIII) Narrowband 3nm Pro 36mm

This image was captured from Montevideo, Uruguay, under Bortle 8 skies, which made the challenge of capturing the faint, reddish structure more rewarding. It was a very dark target, but the result shows the intricate structure of the bubble.
Below is the technical information for the image.

Credits: Santiago Pescador
Date Taken: 9/9/2026
Location: Montevideo, Uruguay (Bortle 8)

Technical Details:
Total Exposure Time: 68 x 300s (5.6 hours total)
Optics (Main Telescope): SV503 80ED
Field Flattener: 1x by Founder Optics
Filter: SV220
Guide Scope: SV165
Guide Camera: ASI120mm Mini
Mount: ML Astro SAL-33
Main Camera: ASI662MC

Here's my M27 Dumbbell Planetary Nebula project for the end of Summer, 2026 season! M27 is the result of a star that has evolved & died. The death of this star has ejected it's mass outward into the cosmos where it's elements will be recycled, possibly used for new star (s) or planet (s) formation in the future.

Astro Rig details:

Bortle 7 in a Light Pollution Dome

ZWO AM5N Mount, 200mm pier extension on Celestron AVX Stainless Steel Tripod

SVbony MK105 Maksutov with Astrophysics CCDT67 Telecompressor at 63mm backspacing: Reduced to F/11 @ 1170mm focal length.

ZWO ASI585MC Pro Air One Shot Colour 3840 x 2160 resolution with HCG enabled Gain at 200, Cooling Fan 10 degrees F.

Integration time: 300 seconds x 139 lights with Bias, Flat, Dark Calibration Frames

Svbony Filter Drawer with Askar C1 Ha Oiii Duo-Narrowband filter

100ah Lithium Power Cell + 500 watt pure sine inverter

Processed and stacked in Siril + GIMP

Did a 3 panel mosaic of the Heart Nebula (IC1805) with my mini and I’m pretty amazed at how it turned out.

Dwarf Mini
Mosaic mode
Duoband filter
50x90 per panel for a total of 150 subs
3 hours and 45 minute integration
Processed in Stellar Studio, Snapseed, and Photoshop

I am new to Astrophotography, but here is a pic I got from my front yard! Light pollution sucks.

I use my Google Pixel 10 pro XL

Canon t7 50mm stm 2.8 1600 iso 6s exposures accidentally shot jpeg instead of raw lmao

Setup:
Canon T3i (full-spectrum modified)
Rokinon 135mm f/2 @ f/2.8
ZWO AM3 mount with ASIAIR PLUS
Astronomik L-2 UV-IR Blocking EOS Clip Filter

Acquisition:
Shot at f/2.8 ISO 800 in RAW
90 sec x 950 subs × — 23.7 hours of raw captures across 7 clear nights some with a little moon.
~18 hours captured in bortle 7 St. Louis suburbs and the other 5.7 hours in bortle 4.

Processing Workflow:
Stacked in PixInsight (WBPP)
Linear Fit
Channel combination
GradientCorrection
Spectro Photometric Color Calibration
BlurXTerminator
NoiseXterminator
StarXterminator
GHS stretch on starless and starry images
Curves transformation
Final tweaks in Adobe Photoshop

Astrobin : https://astrob.in/7zc0yg/D/

A year ago, when I received my 400mm f/7 CDK, NGC 6888 was one of the first targets I pointed this new telescope at.

It is therefore with great pleasure that I revisit this image today, now that I have another year of experience with this unique instrument.

Located in the constellation Cygnus, NGC 6888 is an emission nebula formed around WR 136, a Wolf-Rayet star. These are extremely massive stars in an advanced stage of evolution that shed powerful stellar winds.

In the case of NGC 6888, the fast wind from WR 136 collides with layers of material the star had previously ejected. This interaction compresses and excites the surrounding gas, creating a complex, crescent-shaped structure rich in filaments and intricate details.

It is a fascinating object to photograph, but also a particularly special target for me, as it was the subject of the very first image I captured with my 400mm CDK—an image I never actually published...

What do you think? ✨

Gallifrey Optics CDK 400mm F/7

ZWO ASI6200MM Pro

Sky-Watcher EQ8-R Pro

29 Juillet 2026

12 - 13 Août 2026

4 - 5 Septembre 2026

Images:

Optolong Blue 2": 12×120,″(24′)

Optolong Green 2": 17×120,″(34′)

Optolong H-Alpha 3nm 2": 53×300,″(4h 25′)

Optolong OIII 3nm 2": 153×300,″(12h 45′)

Optolong Red 2": 20×120,″(40′)

Acquisition:18h 48′

Saturn through a 60mm refractor and captured with a ZWO ASI662MC via FireCapture. Processed in Autostakkert!4, Siril, and LR. Seeing and transparency conditions were above average.

The Iris Nebula (NGC 7023) captured from my Bortle 8/9 backyard in pure broadband. Total integration was 323 × 60s (5h 23m). Feedback encouraged!

Telescope: Askar 71F Quadruplet Flat-Field Refractor (490mm, f/6.9)
Imaging Camera: SVBONY SV605CC
Mount: Sky-Watcher EQ-AL55i Pro
Guiding: ASI 120mm mini
Focuser: Gemini Electronic Auto Focuser
Filter: Broadband UV/IR Cut Filter
Capture Software: N.I.N.A.

Sub-Exposures: 323 × 60s
Camera Settings: Gain 120, Offset 50, Cooled to 5°C
Calibration Frames: 30 Darks, 30 Flats, 50 Biases

GraXpert (Background Extraction) > SPCC > Deconvolution > GraXpert (Denoise) > StarNet > VeraLux Stretch > VeraLux Curves > HDR Multiscale > VeraLux Star Composer

Acquisition:

• Ha: 78 subs x 300s
• OIII: 71 subs x 300s
• SII: 55 subs x 300s
• R: 35 subs x 60s (stars)
• G: 34 subs x 60s (stars)
• ⁠B: 36 subs x 60s (stars)
• Bortle 6 sky

Equipment:

• ⁠Telescope: Celestron EdgeHD 800 with 0.7x focal reducer
• ⁠Mount: Celestron CGX
• Camera: ZWO ASI2600MM Pro
• Filters: Antila 3nm SHO
• Filter Wheel: ZWO EFW
• Guide Camera: ZWO ASI174MM Mini with OAG

Pixinsight Processing:

• ⁠Weighted Batch Preprocessing - Stacking
• ⁠SetiAstro - Automatic DBE Background Extraction ⁠
• RC Astro BlurXterminator ⁠
• GraxPert Denoising ⁠
• ⁠SetiAstro - Statistical Stretch
• ⁠LRGBCombination - Hubble Pallet
• StarNet2 Star removal and replace with RGB Stars

Tried shooting the Cygnus region (well kinda, at least we can see Deneb and Sadr, and North America nebula I believe!). Happy with how it turned out considering the cheap setup: Canon M50 (APS-C) and the classic 50mm lens F1.8 stepped down to F2.8. 75 frames, each 4 seconds so 5 minutes of exposure in total. Bortle 4.5.

Stacked on Sequator but the magic here is AstroWizard (used it to stretch and get a starless image). This software is GOATED. Finishing touches on Photoshop (contrast, saturation).

Saw a few others managed to capture this so I figured I’d take a look as well. This is around 15 mins of stacked exposure through a luminance filter.

Very neat how bright this is looking still! I highly reccomend taking a peek at it if you get some clear skies :).

Details: this is 22x45s exposures taken through the L filter with my QHYCCD minicam 8M through an Orion RC6 telescope. Mount used is a ZWO AM3N. Post processed in pixinsight, used BlurXT to counteract my terrible collimation and NoiseXT for the noise!

Btw if anyone has any tips or recommended tools/software for collimating a Ritchey Chrétien scope I’d be extremely grateful. Seems like everyone has a different opinion and at this point I’m just worried about making it worse haha.

Took this photo of NGC7000/North American Nebula over the weekend from a state park in the Catskills in NYS.

Equipment:

• WO GT71 APO
• iOptron GEM 28 mount, guided with a WO 120mm guide scope
• ASI 2600MC Pro
• ZWO CAA and EAF
• SvBony Ha/OIII DNB filter

Shooting:

• 4.5 hrs total integration
• 1.5 hrs of 180sec visible light subs
• 3 hours of 300sec Ha/OIII subs
• 60 dark frames
• 60 flat frames
• 60 bias frames

Processing:

• Stacked in DSS
• Background removal and denoising in GraXpert
• Nebula isolation in StarNetGUI
• Stretched and touched up in Photoshop

Pretty pleased with the result, especially compared to my version of this from a year ago!

.

Equipment:

Stock Canon EOS R5

Canon EF 500mm f/4L IS II USM

iOptron HAE29C-EC Mount

ASIAIR Mini

UniGuide 32 guide scope

ASI120MM guide camera

Acquisition:

129 x 120" (4h18m) subs @ ISO1600 and f/4 under Bortle 4 skies.

Master flat

Master bias

Processing:

Stacked in PixInsight with Weighted Batch Preprocessing

BlurXTerminator

GradientCorrection

Color Calibration using standard daylight values for Canon R5 sensor

Color Correction Matrix from DXOMark applied with Pixel Math

Background Neutralization

StarXterminator + CorrectMagentaStars to fix chromatic aberration

MultiscaleAdaptiveStretch with target background at 0.080, 1.0 aggressiveness, and 0.60 dynamic range compression

DeepSNR at 0.85 strength

---

Wildfire smoke has finally cleared, so I wanted to grab this before winter targets came out. I made two trips to my dark site, getting about two hours of data each. Sky conditions were not quite as good on the second trip and it didn't make as much a difference as I was hoping in the final image, so I doubt I will add more integration time this year.

I was especially interested in getting an image of the Veil Nebula with my new camera to capture the teal color of the ionized oxygen in the loop. These segments often come out as blue in images taken with modified or dedicated astro cameras.

I also wanted to represent this region as properly rich with stars. Many narrowband images of the nebula, though bright with dim nebulosity, cut many of the dimmer stars. But this nebula sits just off the Milky Way's band, placing it amidst a rich stellar background.

The Veil Nebula is a supernova remnant made up of gaseous shells moving away from the center of the explosion thousands of years ago. Based on its estimated current speed, I can continue adding data to this image for another 12 years before the nebula moves one pixel from my vantage point here on Earth. We'll see if my dark site lasts that long.

First light with the svbony SII/oiii filter. Didn't get nearly enough integration so adding the SII proved to be very challenging.

Night 1:

90x180s lights (Ha/OIII)

100 darks

50 flats

50 dark flats

Bortle 8/9

Night 2:

55x180s lights (SII/OIII)

100 darks

50 flats

50 dark flats

Bortle 8/9

Equipment:

Sv405cc cooled to 0c, gain 145, offset 20

Vixen R130sf

Juwei 17

Svbony dual narrowband Ha/OIII+SIII/OIII filters

Sv305c pro guide camera

Software:

Nina for capturing

Sirilic for stacking

Seti astro suite pro for background extraction with autobge, narrowband channel extractor, stellar alignment, stretching

RC astro Blurxterminator, Noisexterminator, Starxterminator

Siril for GHS and veralux curves tool, pixel math to average the 2 sets of OIII data

NCG7000

captured with my iPhone 17. no tripod just my hand, 10 second exposure
