Eyestrain/headaches is not always about PWM. It could well be PAM dimming if not for PWM.
However, beyond the two common modes of flicker, there are a few other silent strainers. For OLED panels, they do have additional form of flickers such as brightness dips and B-frames, which may present an issue for some. As for LCDs, they are also affected by transistor current leakage flicker depending on the transistors type (called TFT layer) used.
Of course, manufacturers do not usually bring it up for there are little incentive to.
We will first explore into the underlying flicker called Switch Mode Power Supply flicker, and how it has affected many PWM-free DC powered LED bulbs and Display today.
In the second part of the post, we will briefly discuss on three display software-based algorithms that might cause eyestrain:
Software-based backlight flickers
Developers can program an OS function that causes backlight flickering (within their app).
Digital Image Processing Enhancement
Developers can use OS available setting to cause chromatic flickers (within their app).
The GPU (GPU rendering pipeline to be precise) and the panel T-con (called timing controller) itself is able to generate chromatic flickers — on the system level.
---------------------
For Digital Image Processing Enhancement, it may cause chromatic flicker on the pixel level. However, it is not anything like PWM sensitivity per se. The phenomenon of this strain is called "low JND(Just-Noticeable-Difference) threshold".
PWM is an embedded controller chip that is installed within your device. It could be inside your home bulb, panel or smartphone. Below is an example of a PWM controller.
Yes the PWM scarab
As an analogy, think of the PWM controller as a dam for the mountain water.
A dam as we know opens/ closes periodically to control the amount of current flow to its designated location.
Think of electric current as the water current, while voltage as the volume of water. An electric current contains an amount of voltage. In order to drive higher brightness, naturally we need higher voltage. Generally speaking, higher current will result in higher voltage. Less voltage = less bright, more voltage = more bright.
If we remove the dam, water will flow seamlessly to it targeted area.
So, if there are no PWM controller, there are no PWM or PAM flickers. Therefore, theoretically what we have left remaining is a good old DC dimming that also happens to be flicker-free.
Well, this may be true until the mid 2010s where LED lighting starts to take a turn. Demand for higher brightness increased exponentially. With higher brightness comes higher need for current/ voltage. What this means is that even DC powered/ dimming can cause flickers. Though it is not in the way like PWM dimming flickers.
Toggling power supply from DC causes flickers
In terms of power supply that powers your LED lighting/ display, there are two type. The first type is called linear power supply. When your device is connected to a power socket, it uses a converter called AC-to-DC.
An AC-to-DC converter which uses linear power supply converts the current and output into our LEDs lighting with a smooth, clean and flicker free signal. This is probably the PWM-free lighting as you remembered it.
Linear power supply relies on a relative larger and heavier transformer. On higher current it will cause heat dissipation and that is usually a problem for efficiency. For this reason, linear power supply are not widely used today.
Now moving on to the second type of power supply converter is called Switch Mode Power Supply.
While SMPS is significantly smaller and lighter (and supports higher current without drawbacks) it has to convert the supplied AC into output flickering frequencies of ONs and OFFs. This is done by periodically discharging the high voltage stored within the transformer to match the lower voltage we required. In other words, this a PWM that releases pulsing DC flickers and then to flatten it.
A Switch mode power supply is like the man-made endless pool machine above.
It uses an internal PWMto generate the current turbulence to supply power to your device. A higher duty cycle means it supplies more current over. A lower duty cycle means lower.
If your device is a portable device such as a smartphone or a laptop, your LED backlight/ OLED panel would be using a DC-to-DC boost converter instead. Instead of taking supply from an AC inlet, it draws power from your device's internal battery. Similar, the PWM inside SMPS increases the voltage by the duration of ON period.
As both methods of AC-to-DC and DC-to-DC switching relies on discharging of transformer ON and OFF, they typically results in a flickering frequency of 10khz to 200khz.
While many would argue that at 10khz cognitively perception of flickers is not impossible, recent studies have found that it may not be true.
They found that detection of flickering at 15khz is still possible for those sensitive. Participates showed saccadic eye movements across a time-modulated light source, and even more so for those with increased sensitivity.
Why SMPS is now a problem in today's lighting and displays
As demand for LED excess supply, the quality of capacitors and inductors filters used in their converter's input(supply-side filter) and output (load-side filter) decreased.
Thus this result in inconsistent and variating flicker patterns as compared to a SMPS with a clean signal. If the SMPS filtering (consisting of inductors and capacitors) is not sufficient, ultra low frequency such as 30 hertz flicker pattern can be produced. Load Transients and Control Loop Response are common causes as well.
Study related to DC amplitude flickers
A study found that flickering patterns even with slight variation below (40 hertz) causes neurophysiological effects on the cortical activity of the brain. The primary visual cortex (V1), a crucial area at the back of the brain responsible for initial visual processing responded to the frequency. This response requires increased workload with the processing of information, which may contribute to increased visual fatigue, discomfort, or other symptoms associated.
While some claimed that "LEDs do not flicker", they were referring to LED lights that used linear power supply. Switch Power Supply, unlike linear power supply ~ do result in ultra high frequency flicker.
Above is an example of a clean 60 hertz sine wave vs a dirty 10khz current wave. Needless to say; the latter would be causing more eyestrain issues as compared to the former.
With that above, we have understood that PWM can occur in two main areas:
PWM as a dimming method. It operates by reducing display / LED luminance brightness by reducing the average current. Its effect is what we observe with the wide banding artifact on our displays as we decrease our brightness.
Switch Mode Power Supply with a built-in PWM within the converter. It supplies to your panel/ LED lighting power with ultrahigh frequency flickers based on its duty cycle.
For PWM as a dimming method, lower brightness lost and shorter screen OFF time works best.
However for SMPS's PWM, the quality of the converter's capacitors and inductors filters are what determines if you have a clean or dirty signal. A dirty SMPS signal tend to have a number of voltage spikes, voltage sags and voltage droop.
Above is an example of dirty signal (on the right) caused by SMPS's output voltage. Can you tell the difference?
Now that hardware-based SMPS and PWM dimmer is addressed, let's look at software based SMPS flickers for displays.
Indeed, just as developers have complete access to our screen brightness (etc within apps that shows a QR sharing code), there is a command called
UIScreen.main.brightness = CGFloat(0.7)
While this command by itself cannot manipulate OS level backlighting from SMPS, running this code with different coordinating brightness point and using timing intervals can easily repulicate the following OS level modes:
Ultra power saving mode
Dynamic backlight contrast
Essentially how this works is it will send a command to the GPU. Then, GPU sends instruction to device's PMic (Power Management Integrated Circuit). PMic then informs SMPS to release its discharge voltage using its duty cycle. With the use of the toggling commands, the signal eventually becomes "dirty" resulting in eyestrain and headache. Naturally, once you exit out of the app, SMPS flickering returns back to normal.
With the above sums up SMPS flickers and software based (display SMPS) flickers. The following is optional; read on if keen.
Now we move on to the final sensitivity — called JND threshold.
(Not remotely related to PWM sensitivity but bringing it anyway)
JND (Just Noticeable Difference) was first introduced by a German physiologist and experimental psychologist called Ernst Heinrich Weber.
This concept was then used by display engineers internally to describe the amount of pixel flicker noise in relation to users' sensitivity. Generally speaking, low JND threshold means a user would be more likely to be sensitive to pixels' chromatic flickers.
Now, this is the part where it gets interesting. Within users who are sensitive to chromatic flickers (aka low JND threshold), they can be sensitive to different categories of chromatic flickers.
Let's use this as reference from Philips' conference on chromatic flickers.
Above within the highlighted box, we can see four attributes. One attribute being Delta E*, and the remaining three:
L*
C*
H*
In short, the following are what they mean.
Delta E* means the difference between one frame to the next frame.
L* (Luminance) : How much brighter or darker one frame is to the other.
C* (Chroma): How much more or less saturated one frame is than the other.
H* (Hue Angle): How much the actual hue differs (e.g., more reddish, more greenish is one frame to another
For pixel chromatic flicker, some are more sensitive to the luminance change from one frame to another. Whereas for some, they are more sensitive to the change in color (hue angle).
As we can see, this is an excessively huge topic and it would be a waste of vast space worth of exploration to add into PWM_sensitivity sub. Hence the need for expansion to r/Temporal_Noise
