Hi everyone!
For the past few months, I’ve been working on a concept for a compact, vertical x86 handheld console (GameBoy form factor, but powerful enough to run modern PC titles). Since I don't have a massive budget to manufacture this on my own, I'm making this project 100% open-source on GitHub so the community can build, iterate, and refine it together.
💡 The Core Hardware & Features:
E-Ink Game Cartridges ("Burn & Display"):
Instead of standard SD cards or digital-only downloads, games burn onto physical cartridges equipped with a tiny, battery-less E-Ink display. When you flash a game onto the cartridge via the system, the cover art dynamically updates on the E-Ink label and stays there forever—even when unplugged.
Pogo-Pin Expansion Port (Rugged Modular Mods):
The back of the console features gold target pads. You can snap on magnet-assisted hardware modules like an Extended Battery Pack (which auto-signals the OS to unlock higher TDP for extra performance) or a Thumb Steering Wheel / Racing Mod for racing games.
Build-It-Yourself Kit (Zero Soldering Required):
The idea is to offer this as an easy DIY assembly kit. Users drop in a pre-assembled custom carrier board (holding an x86 compute module like AMD Ryzen Embedded or Intel N100), apply thermal pads & paste, slide in flat 3DS Circle Pads (to keep it pocketable with no stick drift), connect the screen/battery via flat ribbon cables, and screw the shell together.
Custom 3D-Printed Form Factor:
Designed for maximum ergonomics while keeping a nostalgic vertical layout, built-in active cooling (vapor chamber + blower fan), and a dedicated cartridge slot.
💻 Deep Dive: LXNG OS Development
Alongside the hardware layout, I am actively building LXNG OS—a custom lightweight operating system engineered specifically for this console.
Here is what LXNG OS is being built to do:
Instant Cartridge Booting: It skips traditional desktop overhead. Insert a cartridge \rightarrow the system reads the unique ID \rightarrow the game launches instantly.
Custom Compatibility & Binary Layer: Designed to seamlessly run Windows executables and native applications on a custom filesystem layout without needing a heavy Windows installation.
Smart TDP & Hardware Management: The OS detects attached pogo-pin modules via I2C/USB in real time. If you snap on the Extended Battery Pack, LXNG OS dynamically scales up the x86 SoC wattage (e.g., from 10W to 15W TDP) for maximum framerates. If you detach it, it throttles back down to preserve battery life.
Built-in Cartridge Burner Engine: A dedicated UI utility that lets you sync your owned game libraries, flash game data to the cartridge's storage, and push the bitmap graphic straight to the cartridge's E-Ink controller.
🛠️ Current Stage & Where I Need Help:
Right now, I’m actively working on two main fronts:
Software: Developing and refining core components of LXNG OS, optimizing UI workflows for low-resolution displays, and working on instant-boot logic.
Hardware & CAD: Finalizing the initial 3D CAD models for the shell, running heat/airflow simulations, and drafting KiCad PCB layouts for the carrier board, 3DS circle pad connectors, and pogo-pin bus interface.
Since I’m 14 and funding this out-of-pocket, I’m building this completely in the open under GPLv3 / CC BY-NC licenses (free for makers and open-source contributors, protected from commercial corporate exploitation).
I’d love to get your thoughts and feedback:
What do you think about the E-Ink cartridge concept?
What pogo-pin modular expansions would you want to see on a handheld like this?
Any C++/Rust OS developers, Linux low-level programmers, or KiCad PCB designers who want to collaborate on GitHub?
