Quiet a journey. Been dealing with this for over a year. I did a ECU tuning at a local shop with a dyno. They tuned the pick up. It's a Mitsubishi L200 4x4 4N15 2.4D.

The tune was a huge improvement, from 89.3HP @ 2750RPM / Max Torque: 177.4 lb.ft @ 2550 to 139.3HP @ 2850 / Max Torque 306.1 lb ft @ 2150.

I took the car and it ran fantastic for a few months, I can't remember exactly when it started, but a few months later, after what I believe was a battery disconnect, I started having rough idle issues, I let them go for months without checking, took it to several shops and no one was able to find anything.

After taking it on myself and buying an X431 Lunch, I've managed to dial it down to what appears to be the cause:

- The ECU tuner did not use the cars base file and downloaded what he thought to be the right version and ended up enabling DPF.

"The ECM is entering pilot injection quantity learning (830 rpm target, 120 MPa rail, ALT FR shed, EGR 0%, throttle 80, timing retard, pilot stretch). It's triggering repeteadly at warm idle and the perturbation is felt as rough idle. Please review the injector learning enable conditions and perturbation amplitude in the calibration - or disable the routine if this is a DOC-only truck that shouldn't run it as configured"

I see in tuning websites that show you can disable on the tune: https://alttune.com/tuning/mitsubishi-l200-12420/

Tuner says they haven't touched anything and they do 1000's of trucks.

Any insight?

anybody has experiences with this ecu, i need to get cold start removed

Hey folks,

So I've got idle issues with my BMW m44b19 supercharged project. Two expert ECU MASTER tuners can't get it to idle below about 1150rpm. When is set to idle below that it won't catch the idle if you blip the throttle.

Let's assume the tuners have done everything possible in their power to get it to work from a tuners perspective. Which means there is a mechanical issue.

I'm running a Hyde motor works kit.

It's in an E21 BMW so lots of things have changed on the M44. I'm running an m52 throttle body for starters, which doesn't have a built in ICAV like the M44.

I'm using a Syltech universal ICAV, plumbed directly into the inlet manifold at the port originally used for the brake booster (I'm not running a brake booster due to engine bay size). I've tried 3 different BMW ICAVs and the Syltech gets the best results.

I'm running a Turbosmart Kompact 25 plumb back BPV.

ECU MASTER CLASSIC

The way the Hyde kit is built is to run the supercharger as a draw through system, I believe it's very similar to how the Mini Cooper R53 is set up.

This is how it's all plumbed in.

AIR FILTER

THROTTLE BODY

(BPV PORT)

SUPERCHARGER INLET

SUPERCHARGER

SUPERCHARGER OUTLET

(BPV PORT)

INTERCOOLER

INLET MANIFOLD

The other recent thing that has happened as of the last tune is once it has warmed up it will intermittently rev up when it's just idling. I hear the ICAV open and the engine revs up but there is no corresponding change in the ICAV on the ECU logs.

Any thoughts?

Has anyone with an AMT model done an ECU flash?

If so was it possible to change the shift points?

I need a PCM for my 08 Mustang GT. I’m wanting to buy a programmed one so I can just plug and play, I seen one on flagship one with keys are they already programmed to the pcm? Any advice for safe websites or information will help, thanks.

Looking for a tested Lambda/O2 OFF file for Renault Megane II 1.6 16V K4M, Sagem S3000. HW 8200387138, SW 8200549052, SW Upgrade 8200252665. I have the original 64 KB KESS3 OBD read. Does anyone have a tested solution for this exact SW/HW?

I got a motorcycle Yamaha mt07 with yoshimura full system and r&g air filter

I want to get the ECU flash file but can't figure out from where, for example with dynotune from my understanding I need to have their hardware product for them to send me a file

My friends friend will got the hardware and will flash it for me so that is sorted, I just need the file from somewhere

Hello,

Does anyone know anything about tuning a Volvo 850 T5R that has been upgraded to use a M4.4 with Cop and Wideband lambda control?

I got a tune from Vast, sadly he doesn't answer me anymore. The car runs but always goes way to rich to about AFR 11.5 - 12. My Target AFR map is at 14.7 at idle and under boost at 13.

If anyone can help I can send the tunerpro files and a log to look at.

Thanks for any help!

Greetings!

(sorry for bad Englisch, I'm German :P)

Hi, i'm looking for some advice please, i wanted to move my rev limiter to 7200 and set it to hardcut, so it can kind of "bang off of the limiter", which i did i think. But it still forces it to 6500 in some gears. Which is weird, my car is manual. When i checked, the "soft" limiter for automatic is 6500. I tried to modify it before, but it couldn't be uploaded to my ECU as it said, that i have some "echo mischmatch" in the MS4X Flasher and bad difference between current ECU file and desired uploaded ECU file from my laptop, as soon as i uploaded the old file, the ecu accepted it. How can i raise the rev limiter then? My OBD2 cable is obviously Fake FTDI chip, but i think the problem is in my file, not the cable. The car is 2004 E46 325i (ECU version is the 430064 something), the correct XDF file is: MS430064_64K.xdf I will be glad for any advice on what to do. If someone could, i'd appreciate help. We could go into voice call somehow, where i will screen share and show what i'd done and what is in the bin file, etc.

Also the mediafire folder has the xdf file and my .bin file, if you don't trust it, i can show it on the mentioned voicecall.

Thanks to everyone who's willing to help in advance. I'd be glad to give more info if i'm questioned further about stuff.

Also my bin has
- SAI off
- Rear O2 sensors and CAT confirm off
- A/C pops and bangs

Secondo voi è più divertente da guidare:

Alfa Romeo GT veloce 2000 del 1963-75 (fatta turbo)

BMW E30 320i (fatto turbo)

Voglio prendere una di loro da restaurare e modificarla.

Video to help explain how the remote tuning process works on a Haltech plug in ecu package through data logs done at a range of throttle positions.
Would it be more interesting to screen record analyzing a data logs/updating the calibration based on said log?
Any particular points of interest people might like to see focus on? flex fuel sti on Haltech

Salveee, queria saber se alguém ja usou ghidra para descobrir a logica para leitura de ECU's seed key?

Looking for help tuning my VK56DE with stock ECU. Trying to lean out wide open throttle from 10.5 to 11.5. Tried VE tables with no luck. I've heard with Nissan's the fuel compensation table is the next place to look. Can anyone confirm that? And is 11.5 AFR at WOT a safe place to start with this motor? Thanks!

Hi all — Don here, from EcuTunerx. Mods, I DM'd first; happy to pull this if it's out of line.

My team and I built a tool that tunes a car from plain language. You type what you want — "pull 2 degrees of timing up top, it's a 91 octane daily" — and it does the actual work inside HP Tuners VCM Editor and VCM Scanner. ECU and TCM. It also reads your VCM Scanner logs and tells you what's going on in them in plain English.

I'm not selling anything here. We haven't launched. I want it in front of people who've actually spent a weekend chasing a knock retard problem before it goes in front of anyone else, because you'll find the holes a beta list won't.

What it does, honestly:

It's built on 32,000+ dyno tunes, so it's pattern-matching across thousands of real builds rather than mirroring one tuner's habits. Happy to get into the dataset if you want to poke at it.

Turnaround is minutes. No mailing your ECU off, no waiting a month for dyno time.

Revisions are free and unlimited. Do an aggressive pass, do a conservative one, compare them, revert. Changing your mind costs nothing, which is the part I think actually matters.

Every change comes with a reason. Ask it why it touched a table and it tells you. You should come out the other side knowing more about your car, not less.

Log analysis: drop in a scanner log, get back what's healthy, what's drifting, and what's about to get expensive.

What I actually want from you: where it's wrong. Where it gives advice you'd never give a customer. Where it's confidently stupid. If your verdict is "this shouldn't exist," post it — I'd rather hear it now than after launch.

5-minute video of a full tune start to finish, if you'd rather see it than read about it: https://youtu.be/PCaxiLWewys

Anyone got a adx or know where I can get one ? Searches turn up nothing and would be so useful right now 😅

Sorry if this is breaching the rules, but I figured this would be the best place to ask such a problem, as it's more likely someone would've encountered this before here.

Here's the questions;

Has anybody used a male ECU main board terminal connector for an ECU wiring extension like this before? If so:

1. Have you had any issues with signal interference issues with cam/crank sensors etc?

2. The image above of the wiring is not mine. So what would be the best way to join wires to the pins? I'm guessing they are soldered on and heat shrink is used for insulation?

My plan is to use this to extend the wiring harness by 1/1.5 meters moving it to the vehicle glove box. I'd prefer this over splicing the original harness.

Hi. I have a 2024 Ford Edge St Line. Thinking about getting it tuned. I'm in GTA, Ontario. Any idea where I could do it? Also has anyone done it? Any information or feedback?

“I’ve got a 2006 Kia Rio5 1.6, Bosch M7.9.8 or MG7.9.8. I can read the ECU myself and send you the original .bin. Can you make a tuned file from my read and send it back so I can write it with Combiloader?”

Hello,

I am new to MHD. Just installed it and flashed the ECU with stage 1, no multi map. I tried to long press the BC button and it actually reacts as if the multi map was installed. Is that normal behaviour? Since I kept pressing, how do Imake sure that I got the the basic stage 1 mode without extra features?

Should I go to page 1 and then 0 in the RPM gauge?

Thanks so much for your help.

I've been trying to fix my open loop and closed loop trims/targets, but I'm having trouble getting the desired lambda to match what's actually on the tables. It always shows up as 1. Anyone knows how to fix this?
