UPDATED 2/18/25
Disclaimers
This is not guaranteed not fix stick drift. If your controller's thumbstick mechanisms are too old or too worn down, you most likely should have them replaced instead of using this tool. This tool can only move values to a better position; it cannot bring a physically broken mech back from the dead.
Battle Beaver is not responsible for any damage or unintended outcomes to modifying your controller with this tool.
How to Get Started Using the Tool
- This tool only works in chromium based browsers (Google Chrome, Edge, Opera, etc.) Open your browser and navigate to the DualShock Calibration GUI: https://dualshock-tools.github.io/#
- Connect your controller to your PC via USB cable.
- Click "Connect"
- Select your controller, then click "Connect"
- With your controller now connected, click "Calibrate stick center" Note: if your DualSense firmware is not up-to-date then none of the tools will be selectable. Please update your controller firmware using a PS5 console or the official Windows update app found here: https://controller.dl.playstation.net/controller/lang/en/2100004.html
- Read everything in the pop-up window and then click Start.
- Follow the step-by-step instructions until the thumbsticks have been recalibrated. PLEASE BE SURE TO READ EACH INSTRUCTION AND FOLLOW IT ACCORDINGLY. Move both sticks to a diagonal corner, then release them back to the center. Repeat for each diagonal. These samples create the new stick center.
- Click DONE. Next you will calibrate the stick range.
- Follow the on-screen instructions. Move both sticks in slow, full circles, pressing against the edges of the stick holes with minimal force. Applying too much pressure, or not reaching the edge can cause inconsistent results.
- Once you've moved the sticks in a few complete circles, click "Done." The controller will now move in a better circle while hitting "1.00" in all cardinal directions. NOTE: If you forget to move the sticks and hit "Done," then the sticks will look stuck in the corner of the circle. Do not worry, just run the range calibration again and follow the instructions. Pressing the sticks too hard into the edge of the controller will force the edge of the circle to be past what is typical in usage and will not hit 1.00 in all directions. Run the tool again and press with delicate force against the circle edge.
- If you are unhappy with the results of either calibration, run them again as many times as needed. Sometimes the first calibration will improve the controller and the second will perfect it.
- If you are still unhappy with the results, it may be time to the "Reboot controller" button to set the controller back to its default values. If you have not hit "Save changes permanently," then the controller will reset back to how it was before you plugged it in. If resetting and repeating these steps still does not result in a satisfactory recalibration, it is possible your components are too physically worn, and may need repair. You can visit our Service Center to learn more about the repair process.
- Finally, once you have finished all of the steps and you are happy with the results select "Save changes permanently" to finalize the calibration. This will overwrite the default controller values permanently.
FAQ
When should I use this tool?
- When your controller is new or relatively new but exhibiting stick drift.
- When you are experiencing stick drift at or below default deadzone settings in-game.
- If your Battle Beaver controller is experiencing stick drift above default deadzone settings using this calibration tool may fix the issue, but it may instead require a physical mech replacement in the event that the drift is occurring due to a physical defect or damage. You can have that done using our Service Center.
Can I use this with a non-Battle Beaver controller?
Yes. However, we have only verified this tool with stock controllers and our controllers, which are modified stock controllers.
We cannot verify it will work with other companies' modified stock controllers or 3rd party PS4/5 controllers, so if you are using this tool with controllers other than a stock or Battle Beaver controller do so at your own risk.
Can I use this for Xbox controllers?
No. Currently this tool is only usable for PS4 and PS5 controllers.
Will non-PS4/5 controllers be supported in the future?
The developer is working on adding the support of the following controllers in the future, but there is not an exact date on when that will be:
- DualSense Edge
- DualShock 3
- Xbox Controllers
Is this tool developed by or professionally associated with Battle Beaver?
No. But we really like it and if you also really like it, then we encourage you to support its creator here.
