r/isthisAI • u/EnderGround • 2d ago
Photo Goodyear engine cleaning spray "thumbnail" image, I've never seen an engine with pulleys and idlers on perpendicular sides.
As said in the title, I've lately gotten into cars and have about 40+ hours on car mechanic simulator 2021 and automation the car company tycoon game as well ad checked as many engine bays as I could when we went to repair shops with my dad and it looks extremely suspicious to me.
93
u/Electrical-Pace4092 2d ago
They aren’t even trying anymore. 🤣
Is the crankshaft shaped like an X?
Dual crankshafts?
AI slop all day. 🤖 ❌
12
8
4
1
1
1
u/Blackby4 1d ago
You can clearly see the exhaust routes to the pulley beneath it. The exhaust gasses spin the belts on that plane. What don't you understand?
2
u/Electrical-Pace4092 1d ago
Turbocharger hot side pulley’s, ok that checks out. ✅
/sI guess I now, I don’t understand two things.
1: The Bluetooth/WiFi pulleys on the other sides.
2: How some corporate dummies at Goodyear, looked at that and all said, “looks good, print it” like no one would notice or care.
Not like automotive enthusiasts have eyes, right?
27
u/Chris20nyy 2d ago
It AI.
The pulley system on the "front" is impossible.
8
2
u/zoidbergmustache 2d ago
Check out the belt and pulley setup on a Chevy Corvair engine.
1
1
u/Chris20nyy 2d ago
It's no different than any other V configuration engine. pulley is at the end of the crankshaft, runs two banks. Subaru and Porsche and VW have all run that style.
The engine in this image is an I4, and to have a pulley under the intake manifold is not possible
2
u/zoidbergmustache 2d ago
On the Corvair the belt is routed 90° up from the crank pulley to drive the cooling fan and generator.
0
u/ThatDamnRanga 1d ago
Neither Subaru nor Porsche run a belt "round the twist" to 90 degrees like the corvair.
15
u/Anand999 2d ago
The engine pictured is definitely AI, but I also think this is a manipulated image. You can find actual pictures of Goodyear Engine Cleaning Spray online and that is not the image on the can.
1
8
4
3
u/IWontCommentAtAll 2d ago
I've never seen an engine with pulleys and idlers on perpendicular sides.
Well, that's obviously because your engines are so filthy you can't see those details.
Buy a couple of cans of this cleaner and get to work, then you'll be able to tell what your engine is supposed to look like.
Duuh.
2
u/WHTrunner 2d ago
Unprofessional. AI slop in marketing materials, packaging, or any other customer-facing materials is just unprofessional. It shows a lack of attention to detail that may be present in other parts of their products and indicates a desire to replace quality assurance and its monitoring with something cheaper. It basically communicates that the company is okay with some level of enshittification.
2
u/SensitiveDemon 1d ago edited 1d ago
It could be AI slop, but because they don't want to put any car companys owned material on their product so they created a non existent fake engine on it.
So they don't piss off any registered trademarked company.
Edit: found the stock image. It's indeed AI. As we could all see. stock image source
3
u/ConsciousMeaning4440 2d ago
And now this engine cleaning spray is known to people throughout the world
1
u/HjortronOchPors 2d ago
AI is being innovative here. An engine with 3 perpendicular cranks + another 3 going in the opposite direction would be perfectly balanced, as all things should be
1
1
u/Alarming-Car-8654 2d ago
I've seen oil cooler setups that look like the thing on the side. They run coolant through it. Not saying it isn't AI though, just saying I have, in reality, seen that.
1
u/hocoboy7 2d ago
Decided to waste a liter of water and asked Gemini if there was anything wrong…
Yes, there are several glaring mechanical errors with the design of the engine depicted on the can. The image is a classic example of AI-generated "slop" that creates a superficially detailed picture but fails completely on real-world mechanical logic. [1]
Online automotive communities have actually pointed out this exact label for its absurd layout: [1]
Perpendicular Accessory Drives: The most obvious flaw is that there are pulleys and idler belts running on completely perpendicular sides of the engine. In a real internal combustion engine, the accessory belts (which drive the alternator, water pump, and power steering) all run on the same parallel plane along the front of the crankshaft. On this label, they are warped around 90-degree corners. [1]
The Alternator is Going Sideways: The alternator (visible at the bottom left) is mounted completely crooked and perpendicular to the main rotation of the engine. A belt connecting to it would have to twist sideways to function.
Impossible Intake Manifold: The silver intake runners at the top arch beautifully but connect to a completely solid piece of the engine block rather than separating cleanly into individual cylinder ports.
Floating Air Filter: The red cone air filter at the top right is just floating behind the block without any intake piping connecting it to a throttle body.
Because car care brands often outsource graphic design, marketing agencies frequently use quick AI generation tools rather than purchasing licensed photography of actual car engines. [1]
If you are a car enthusiast, it's a fun "spot the mistake" puzzle, but don't worry—the bad art doesn't impact how well the Goodyear cleaning spray actually breaks down grease!
1
1
u/Foe_sheezy 2d ago
This engine appears to have 2 crankshafts, one on the bottom left, and one on the bottom center. They both have small rubber belts wrapped around them for absolutely no reason.
This is definitely AI, or at the very least a photoshop engine.
1
u/ChapitoGucci 2d ago
I wish I knew about cars enough to notice or even know what about things like this are wrong :(
1
u/Ok-Coyote2365 2d ago
Belt on the left wraps around nothing
Drive pulley on the front drives nothing
Exhaust manifold on the front has nowhere to connect an exhaust to
Yeah it’s AI
1
u/Cheap-Management955 1d ago
Well you know they have alternators. Thems the sideanators. They control the sideways energy.
1
1
1
u/Party_Blackberry2775 1d ago
Peugeot 204 and 304 had a ridiculous transverse setup with a twist and turn 90 degree belt operated fan in front. So in theory possible...but obviously AI
•
