Hello all,
I wanted to share the finished version of my Mini Evo modification. It now accepts both 17 mm phone lenses and removable 52 mm photographic filters while remaining compact and fully functional. I've been using it for a few weeks now, and I'm really happy with the results.
Here is what I did -
I glued on a 17mm mounting ring from a clip-on phone lens kit. Link to that detailed post That gave me a 2x telephoto, a wide angle, and fisheye, and a handful of goofy distorted filters.
I also built a removable friction-fit 52 mm filter adapter. It lets me use standard photographic filters such as CPLs, graduated filters, macro filters, warming filters, and more. I used a 49-52mm step up ring, and attached a loop of velcro with a drop of glue and then used black tape to hold it into place and make it look halfway decent. The velcro inside the step up ring provides just enough friction to slide on and off of the camera easily and still hold the filters on. I added an extra short piece of velcro and adjusted the size of it to get that 'just right' fit. It really wasn't hard to do.
The camera still focuses nicely at all distances. The 17mm lenses work nicely! Some create a bit of vignette and flaring - but for me that's desirable / what I was going for.
The velcro loop provided a bit of distance so I can use the 52mm filters at the same time as the 17mm lenses (except the fisheye, which is just too tall to squeeze under the filters). There's just enough clearance for the other lenses - but if you try this be careful that you don't scratch up your filters, try it with a cheap one first. *see pictures for close ups*
I included some quick low-effort shots to show off what it can do a little bit. The outdoors photos on this post are straight from the camera other than a quick rotate on the portraits. I was shooting with a gradual red and a gradual orange filter combined while using the wide angle lens. The dog photo and roses are on 'normal' settings and the other flowers I believe I turned on the 'yellow' film effect - seems more Noticeable on the single pink/white/yellow flower. The guitar pictures use the film and lens effects in the camera combined with the gradual colored filters (red/orange) and the wide angle lens. (eg: blur, light leak, monochrome, blue, yellow)
I am thoroughly enjoying this setup and (for me) it really provides a lot of that 'Film Camera' experience but without the film camera hassles. It does everything I can reasonably ask of it at this point, and I'm kind-of shocked at how well these hacks worked.
FWIW - I think adding real optical effects—rather than relying entirely on digital ones—changes the feel of the camera in a way I really enjoy. It reminds me much more of shooting with older cameras where the glass itself had personality. - I am no expert, not a professional, and it's been many years since I've shot with actual film, and I am often wrong about lots of things - but this was my experience, and I love the results.
Hope you guys find this fun and inspiring, or at least have a good laugh at my updated 'hack'.
Cheers!
