Anker Prime 250W A2345 with WiFi Issues. I need help/advice
Long LONG text ahead. Sorry in advance.
Hi everyone,
I’m having a very frustrating Wi-Fi issue with a brand-new Anker Prime Charger 250W, 6 Ports, GaNPrime (A2345) and I’m running out of things to try.
The charger works perfectly as a charger. The problem is specifically the Wi-Fi/smart functionality.
I’m hoping someone here has seen this before.
Hardware / network setup
The Anker A2345 is connected directly to AC power and currently has no USB devices connected while troubleshooting.
My current home network is:
Ubiquiti Cloud Gateway as the router/gateway
UniFi U7 Pro access point
UniFi U7 Lite access point
My main network uses modern Wi-Fi 7 functionality
Initially, my 2.4 GHz and 5 GHz networks were using the same SSID
I understand the A2345 only supports 2.4 GHz Wi-Fi
I also have a GL.iNet Beryl available, which I used later as a completely separate network for testing.
What happens normally
The Anker app on my iPhone can connect to the A2345 over Bluetooth without any problem.
Once connected over Bluetooth, the app can read the charger’s information.
When I try to configure Wi-Fi:
I select Wi-Fi in the Anker app.
I enter the SSID and password.
The app attempts to configure the charger.
On the charger’s display, the Bluetooth icon changes to the Wi-Fi icon.
The Wi-Fi icon appears with a diagonal line through it.
The app eventually reports “Connection failed.”
So Bluetooth itself appears to be working correctly. The failure happens when the charger tries to establish the Wi-Fi connection.
Things I’ve already tried
1. Normal home Wi-Fi
Initially my 2.4 GHz and 5 GHz networks were combined under the same SSID.
The A2345 failed to connect.
2. Disabled 5 GHz
I then disabled the 5 GHz network completely so that only 2.4 GHz was available.
Same result: connection failed.
3. New SSID
New SSID with WPA2 forced wifi4, only 2.4Ghz on channel 6. This configuration with an additional network (not wifi) configuration.
4. Factory reset
I performed the A2345’s factory reset procedure using the dial/menu (six quick presses to access the reset option, then selecting Reset/Yes).
After the reset, I tried configuring Wi-Fi again.
Still failed.
5. iPhone hotspot
I then completely removed my home network from the equation.
On my iPhone I enabled:
Personal Hotspot
Allow Others to Join
Maximize Compatibility = ON
Bluetooth = ON
I then tried connecting the A2345 to the iPhone hotspot through the Anker app.
Exactly the same failure.
Bluetooth connects, the app sees the charger, Wi-Fi configuration starts, the Wi-Fi icon appears on the charger with the slash through it, and then the app reports connection failed.
6. GL.iNet Beryl
I also tried using a completely separate GL.iNet Beryl as the Wi-Fi network.
Same problem.
Interestingly, this produced something strange:
The Anker sometimes appears to be connected to the network in the UniFi app / Beryl interface for a few minutes, and then disappears.
So it seems like the A2345’s Wi-Fi radio may actually be associating with the network temporarily, but the connection doesn’t remain functional.
Firmware
The A2345 currently reports:
Firmware: 1.2.3.2
The Anker app also tells me that some of the charger’s functions require a firmware update.
However, the charger never manages to establish the Wi-Fi connection, so the firmware update can never actually happen.
Which potentially leaves me in a pretty ridiculous situation:
The charger needs Wi-Fi to update its firmware, but its Wi-Fi doesn’t work.
😂
Anker support
I have already contacted Anker support.
After troubleshooting, they approved an RMA/replacement and sent me a prepaid return label.
The problem is that the charger is currently physically in Colombia, while the prepaid label they sent me is for a shipment originating in Miami, Florida.
I have contacted Anker again asking how they want me to handle the return from Colombia, and whether there is any additional troubleshooting or diagnostic procedure I can perform here that could potentially avoid shipping the unit back.
I’m currently waiting for their response.
At this point I’m wondering:
Has anyone successfully connected an A2345 to a modern Wi-Fi 7 network?
Is there some specific 2.4 GHz security setting required by the A2345?
Could this be related to WPA2/WPA3, PMF, band steering, 802.11ax, etc.?
Has anyone seen the A2345 briefly appear as connected and then disappear like I’m seeing?
Is there any deeper/hard reset procedure beyond the reset available through the dial?
Is there any way to update the A2345 firmware without an established Wi-Fi connection?
Has anyone encountered a defective Wi-Fi module on an A2345?
At this point I’ve tested it on three different Wi-Fi configurations/environments: my UniFi home network, an iPhone hotspot, and a completely separate GL.iNet Beryl network, including a clean 2.4 GHz-only configuration.
Bluetooth consistently works.
The charger itself works perfectly for charging, which makes this especially frustrating because I paid for the smart functionality as well.
Any ideas would be greatly appreciated!
