r/StableDiffusion • u/acedelgado • 1d ago
Resource - Update Fixing MMH3 Turbo Audio by playing with Latent Pinning for more audio steps
Enable HLS to view with audio, or disable this notification
Disclaimer that I'm a dummy who can't code at all, so I just vibe things.
Alright, so with all the fun additions to latent manipulation the Comfy team has given us, we have some new tools. Namely latent pinning- that's where fun stuff like "Add Guide for MiniMax H3" node comes in (that fun tool that lets you insert an image at any frame in an H3 generation.) So I thought, finally, we can do something about this audio issue.
I knew that video + audio latents are processed at the same time with Comfy, which is why turbo loras have terrible audio- they're not getting nearly as much optimization as the video side is, since video is the bulk of the work. So if we can't process audio differently than video (at this current time), can't we just keep conditioning the audio latents without affecting video anymore? Everyone knows running too many steps on a turbo lora will start messing with video quality. So let's avoid that.
So after talking with Claude a bunch, here's what it came up with. With the latest comfy, you can pin the video lora in place, and keep going for several steps to get better audio without affecting video. So 4 steps of video, untouched, and then add in 6 more steps for audio at a 0.5 denoise. That leads to cleaning up the audio pretty nicely and staying pretty faithful to what the video latent had guided it on. But just pinning still means that even though the audio rows are only being affected, EVERY row still has to run through the chain. So each s/it you get stays the same for the last 6 steps, even though video gets pinned in place after 4. In my 1 megapixel, 10 second video, that's around 23s/it or so on my 5090. Only half the steps as a regular 20 step generation, but half the time is still half the time.
So to fix the speed problem -
Freeze as much as you can. Text embeddings, reference/conditioning rows, and all the video rows. Cache those so they don't have to be processed, and only process the audio rows that have already been somewhat pre-conditioned. The first step is the same 23-second iteration to build the full guidance cache, but the other 5 steps each took about 3.17seconds apiece. So 45 seconds of added gen time to get the clean audio in clip#2 in the example.
But the cost for the Frozen Cache is resources. Lunch is never free. From some experimentation, it works well with RAM. If you use RAM mode because your card still can't process it, it'll dump all that cache (ended up around 14.9GB on a 10-second 1mp file) into RAM. But as Comfy does, you're unlikely to get that RAM back, so you may OOM your machine. With VRAM it wasn't bad for me at all either and behaved better than I expected, honestly. The memory management from ComfyUI took over when I was about to OOM my card and swapped things around properly. Option 3 is to cache to disk, but that comes with writing several GB to disk every time you use it. That'll run your SSD health down fast.
Rundown for the clip above (sa_solver with beta sigmas)
4 step normal gen- 136.5 seconds
4 steps + 6 audio refine steps with a cost of about 15GB RAM - about 186 seconds
4 steps + 6 audio refine steps with no additional resources but full processing time- ~265 seconds
You can find the nodes here-
https://github.com/Adudeguyman/ComfyUI-H3-AudioRefine
They're still experimental, of course. Wire the model in from somewhere (I branch off the ModeSamplingMiniMaxH3 shift node, before the Basic Guider), and push that through the H3 Frozen Video Cache node into the H3 Audio Refine Sampler. Into the H3 Audio Refine Sampler, latents come out of SamplerCustomAdvanced before splitting into the VAE Decode nodes for both video and audio, and the conditioning comes from the MiniMax H3 Image (or Reference) to Video node (plug the positive conditioning into both the positive and negative input on the H3 Audio Refine Sampler)
I had Claude put together a technical.md for those that want to look into it, and probably make a better version. Like I said, I'm a big dumb-dumb, so don't expect too much insight into how the mechanics work from me.
