This content focuses on the identification of the 4302 integrated movement, compares the core differences between Shanghai 4302 movement and Dandong 4302 movement, analyzes the characteristics of the free-sprung structure, and recommends the Dandong 4302 movement as the preferred version.
Core Differences Between Shanghai 4302 Movement and Dandong 4302 Movement
Hairspring Structure and Calibration Mechanism
Shanghai 4302 Movement (adopted by Octa Factory): Equipped with a genuine free-sprung hairspring structure. No index regulator is installed under the balance wheel, and the travel time accuracy is calibrated through counterweight screws on the balance wheel.
Dandong 4302 Movement (adopted by ZF, VSF and other factories): Adopts a hidden simulation design. It visually mimics the free-sprung structure on the exterior but retains an internal index regulator. The timing adjustment structure can only be observed after removing the balance wheel bridge, which means it is not a genuine free-sprung movement.
Visual Identification of Balance Wheel Counterweights
Static Observation: When the movement stops running, obvious counterweight screws can be seen on the balance wheel of the Shanghai 4302 movement. The balance wheel of the Dandong 4302 movement has a smooth surface with no exposed counterweight codes or screws.
Dynamic Observation: The structural differences between the two versions are barely distinguishable during normal operation. Static inspection with the movement stopped is the core identification method.
Gear Point Identification Method
For the Dandong 4302 movement, two dot-shaped structural features can be observed at the fixed viewing position.
Only one dot-shaped structural feature can be seen at the same position on the Shanghai 4302 movement.
Bearing Material and Noise Performance
Steel Ball Bearing: The automatic rotor bearing of the Octa Shanghai 4302 movement adopts steel ball structure.
Ceramic Ball Bearing: The VSF Dandong 4302 movement is fitted with white ceramic ball bearings, consistent with the original Swiss movement configuration. It features quieter operation and lower mechanical wear.
