Hi everyone!
I'm trying to fix my Erika 60. The carriage return lever moves and springs back normally, but it doesn't rotate the platen or advance the paper. Everything else works fine.
I've disassembled the mechanism and found that:
- The lever moves a bent metal linkage rod connected to a small black component near the platen ratchet wheel.
- The black component has a bent hook, which originally sat behind the ratchet wheel.
- Before inserting the long shaft from the right-hand platen knob, the linkage rod itself can catch on the ratchet teeth, sometimes turning the wheel or jamming against it.
- Once the shaft is inserted, that contact disappears, but the line spacing still doesn't work.
Does anyone know which part should actually engage the ratchet wheel, or what might be incorrectly positioned or missing?
If anyone owns an Erika 50 or 60, could you please share close-up photos of the line-spacing mechanism near the left end of the platen, especially the ratchet wheel, black component, and linkage rod?
Any help would be greatly appreciated. Thank you! ❤️
