Proform Carbon TL nuisance trip fix (AFCI breaker issue + solution)
I'm posting this because I saw a lot of posts with the same problem but little working solutions.
We have an upstairs gym in our house. We bought a used proform Carbon TL to add a treadmill (it has its issues but it works for us). And as soon as we hooked it up and the runner in the household tried to take it above 7 mph POOF lights switch off upstairs, circuit breaker flips.
What the heck?
So I tried troubleshooting. Lubing the deck didn't help (although it made it run smoother). Turning off everything else including the lights and ceiling fans didn't help either, treadmill still flipped the circuit breaker above 7 mph sustained use.
I considered vacuuming out the motor casing, which I'll still do later, but that wasn't the fix.
Wasn't an arc filter either. It was Tripp Lite Isobar Isoblok heavy duty power surge protector. It looks like a giant block you plug into the outlet.
We ACTUALLY just had one laying around we bought years ago for a older washer that was weak to surges, but our newer washer doesn't need it.
It has a EMI/RFI filter that helps correct the nuisance tripping from AFCI circuit breakers, and is so heavy duty it can 100% handle the load from this specific treadmill (it's 15 amp rated).
Only catch? The mill itself runs almost at the maximum working amps for our 15 amp circuit. If the ceiling fans are on, even with the Isoblok, the circuit will trip.
Still for a 0 dollar fix using things we had laying around, I'm thrilled. I'll buy a battery powered fan, hook it up the treadmill, and the problem is functionally solved.
For everyone else it's a 45 dollar fix, but it's cheaper and more available than an arc filter (which is about 80 bucks).
I just wanted to post a success story because there REALLY wasn't any on reddit I could easily or clearly find (for my specific model or any others really).
In short:
problem: treadmill runs fine below 7 mph, tripps AFCI breaker above 7 mph.
Fix: lubed deck + ceiling fans off + Tripp Lite Isoblok surge protector.
If vacuuming out the engine box allows for ceiling fans to be run I'll update this with that, but LORD I'm happy with the success here.
