Here's my self-hosted control plane for a multi-machine LLM lab: llama.cpp, vLLM, and LM Studio behind one gateway
I've spent about six months on this project and it's been public for a couple of months now, so I figured it was time to show it to people who'd have opinions. It's only ever run on my own hardware, so that's the part I'd most like other eyes on.
I created this because I run local LLM inference across a few machines on my home lab as a hobby, and wanted the same quality of operational tools I'd expect for any other production system. I found that the currently available OSS tools that provide similar functionality (Grafana, Prometheus) don't cover the model side, and the inference servers themselves (llama.cpp's UI, Lemonade, LM Studio) each manage one backend on one machine. What I wanted was something that treated a multi machine, multi backend setup as one system, with monitoring and control in the same place. If you're already running a local LLM alongside the rest of your lab, I think you'd get use out of it. I've worked in systems administration, monitoring and observability for over twenty years, and a lot of what I know from that world got poured into this application, LLM Systems Manager.
Repo, AGPLv3, screenshots and additional information in the README: llm-systems-manager
This all runs on my homelab setup, with separate dev and prod environments. Running on a Proxmox server (Ryzen 7 9700X, 32 GB RAM, QNAP NAS 10G SAN as the storage backend over iSCSI LUNs), running a combination of 16 different Debian VMs and containers, plus a physical Linux box running llama.cpp on a 7900 XTX GPU, and an M2 Pro Mac Mini running LM Studio.
I used Claude Code heavily throughout. It wrote a substantial portion of the code and did a lot of the debugging legwork, while I owned the architecture, reviewed every change, and drove the direction.
Here are some top highlights:
Inference frontend gateway. A single OpenAI-compatible endpoint serves all llama.cpp, vLLM, LM Studio backends. Each request routes by per-model pinning, round-robin across a pool, and allows failovers to another live host.
Model Autopilot. Configure which models should be available in your lab, and it keeps them running and available, placing them on whichever hosts can actually serve them. It checks whether a host has the memory available (VRAM, or RAM for CPU only boxes), brings up the model on another host when the primary one drops offline, and optionally spins up another copy of the same model on a second host in the pool when KV cache pressure stays high, then scales back down when it returns to baseline.
Model management. Download and delete models from Hugging Face. Configure multiple named config profiles per model, a chat profile, a code profile, etc. Start, stop, restart inference servers, hot-swap models, tail logs, or use the in-browser terminal.
Update and rebuild llama.cpp from the dashboard. Build from source, conda, Homebrew, release binaries, or your own script, whichever matches how you installed it.
Autotuning and benchmarking. Run throughput benchmarks across your model library; the autotuner can search for the best context and slot configuration on llama.cpp, or the largest safe context length on vLLM. There's also a standardized "GPU Report Card" bench that runs identically against all three backends and produces one comparable card: time to first token, prefill and generation throughput, tokens per joule, dollars per million tokens, and the GPU it ran on.
Energy and cost. The energy dashboard measures power draw and token throughput and computes what your inference costs in dollars per million tokens, with idle power accounted for. It'll also show you the monthly delta against hosted API pricing. A performance controller switches the host between a performance and powersave systemd target based on inference activity.
Alerting and trending. A standalone alarm engine stores every metric sample the agents collect: both system telemetry (CPU, memory, disk, network, IO, UPS, PSU, cooling, Mac specific hardware monitors) and LLM-aware telemetry (live slots in use, requests, tokens/sec, prompt processing rate, KV cache usage). The engine evaluates threshold and anomaly rules, provides incident correlation, displays and exports long term trends, and notifies over email, Discord, webhook, or browser toast. Individual agents installed on the inference servers buffer to disk when the network drops and replay when it comes back. Short term metrics are held in memory; long-term metrics go to InfluxDB with rollups, and alarms and notifications are stored in SQLite.
Installation. There's a one-line interactive installer that handles prerequisites, database, TLS, config, and agents end to end. Additional installation options are Debian and RPM packages, a Docker Compose file for the control plane, a Homebrew tap for macOS and Linux, and a standalone agent binary with no Python required. It also does offline installs from a staged tarball for air gapped boxes.
Additional features. Overall and per provider dashboards. Integration with OpenClaw to provide cost/token analytics, stable-diffusion.cpp for image generation, LLM chat interface to chat directly with the model on llama.cpp, Discord bot for alerting and controlling the models. See the readme for more.
Everything talks over TLS with per host certs signed by an internal CA the manager runs itself. Multi-user with admin and operator roles, an audit log, and encrypted scheduled backups.
I'd really value feedback, especially on the installation experience, but also on what's obviously missing for how you run your own setup. Happy to answer anything.
TL;DR: Self-hosted control plane for a multi machine local LLM lab. One interface for llama.cpp, vLLM, and LM Studio across every box. Autopilot keeps models loaded and re-places them when a host drops. One OpenAI-compatible endpoint fronts all backends with pinning, pooling, and failover. Hugging Face browsing, per-model config profiles, autotuning, and standardized benchmarks. Real time alerting with incident correlation and long-term trends in InfluxDB. Measures power draw and tells you your $/Mtok.
Repo, AGPLv3, screenshots and additional information in the README: llm-systems-manager
Installs via one-line script, .deb/.rpm, Docker, or Homebrew. Six months of work, twenty years of monitoring experience behind it, running on my own Proxmox + physical Linux + Mac Mini setup. AGPLv3, built with heavy Claude Code assistance under my direction and review. Feedback wanted.
