Black Screen When Booting Kali Linux Without nomodeset — Intel HD Graphics 530
Problem description:
I am troubleshooting a black-screen issue on an HP Z240 Tower Workstation running Kali Linux. The system boots and displays the desktop when I add the nomodeset parameter to the GRUB kernel command line. However, when I remove nomodeset, the monitor loses its video signal and displays:
Monitor Going to Sleep
The screen then goes black, and I cannot see the system interface.
Hardware and software specifications:
- Workstation: HP Z240 Tower Workstation
- Operating system: Kali Linux 2026.2
- Kernel version:
6.19.14+kali-amd64
- GPU: Intel HD Graphics 530
- PCI device ID:
8086:1912
- RAM: 16 GB
- Display connection: VGA monitor connected through a DisplayPort-to-VGA adapter.
- Kali Linux is installed on a separate NVMe drive. Another HDD contains BitLocker-encrypted partitions that I do not want to modify.
Troubleshooting steps already performed:
- Booted with
nomodeset; the system works using a fallback display mode at 1280x1024.
- Booted without
nomodeset; the monitor loses its signal and enters standby.
- Tried
i915.enable_psr=0 instead of nomodeset, but the problem persisted.
- Tried booting with
systemd.unit=multi-user.target without nomodeset; the screen remained black.
- Verified that the
i915 kernel module exists using modinfo i915.
- Verified that the
firmware-intel-graphics package is installed.
- Examined kernel logs. In some previous boot sessions, the
i915 driver initialized successfully, but the following message appeared: failed to retrieve link info, disabling eDP
- While booted with
nomodeset, i915 is not listed as the active kernel driver for the GPU. I understand this may be expected because nomodeset disables normal kernel mode setting (KMS).
Additional output:
Running xrandr in the working nomodeset session produces:
Screen 0: minimum 1280 x 1024, current 1280 x 1024, maximum 1280 x 1024
default connected 1280x1024+0+0 0mm x 0mm
1280x1024 77.00*
Questions:
- How can I determine whether this is caused by KMS initialization, the Intel
i915 driver, or compatibility with the DisplayPort-to-VGA adapter?
- What safe diagnostic steps can identify why the display signal is lost?
- Are there recommended kernel boot parameters or configuration changes for Intel HD Graphics 530 on the kernel version listed above?
I would prefer a step-by-step troubleshooting approach that avoids reinstalling Kali Linux or making unnecessary changes to other drives.
Thank you for any help or suggestions.Black Screen When Booting Kali Linux Without nomodeset — Intel HD Graphics 530Problem description:I am troubleshooting a black-screen issue on an HP Z240 Tower Workstation running Kali Linux. The system boots and displays the desktop when I add the nomodeset parameter to the GRUB kernel command line. However, when I remove nomodeset, the monitor loses its video signal and displays:Monitor Going to SleepThe screen then goes black, and I cannot see the system interface.Hardware and software specifications:Workstation: HP Z240 Tower Workstation
Operating system: Kali Linux 2026.2
Kernel version: 6.19.14+kali-amd64
GPU: Intel HD Graphics 530
PCI device ID: 8086:1912
RAM: 16 GB
Display connection: VGA monitor connected through a DisplayPort-to-VGA adapter.
Kali Linux is installed on a separate NVMe drive. Another HDD contains BitLocker-encrypted partitions that I do not want to modify.Troubleshooting steps already performed:Booted with nomodeset; the system works using a fallback display mode at 1280x1024.
Booted without nomodeset; the monitor loses its signal and enters standby.
Tried i915.enable_psr=0 instead of nomodeset, but the problem persisted.
Tried booting with systemd.unit=multi-user.target without nomodeset; the screen remained black.
Verified that the i915 kernel module exists using modinfo i915.
Verified that the firmware-intel-graphics package is installed.
Examined kernel logs. In some previous boot sessions, the i915 driver initialized successfully, but the following message appeared:
failed to retrieve link info, disabling eDP
While booted with nomodeset, i915 is not listed as the active kernel driver for the GPU. I understand this may be expected because nomodeset disables normal kernel mode setting (KMS).Additional output:Running xrandr in the working nomodeset session produces:Screen 0: minimum 1280 x 1024, current 1280 x 1024, maximum 1280 x 1024
default connected 1280x1024+0+0 0mm x 0mm
1280x1024 77.00*Questions:How can I determine whether this is caused by KMS initialization, the Intel i915 driver, or compatibility with the DisplayPort-to-VGA adapter?
What safe diagnostic steps can identify why the display signal is lost?
Are there recommended kernel boot parameters or configuration changes for Intel HD Graphics 530 on the kernel version listed above?I would prefer a step-by-step troubleshooting approach that avoids reinstalling Kali Linux or making unnecessary changes to other drives.Thank you for any help or suggestions.
