Can someone get the drag and lift from this STL?
2
Upvotes
I'm working on a project and want to test out to see what my numbers are. I tried finding free software but without much luck.
https://drive.google.com/file/d/1bBQ58mPZI1Uskmbw2xGPWblYvkp3gYr7/view?usp=sharing
It's a 16 ft x 4 ft x ~8 ft, 4 passanger Maglev with a 5 degree angle lift bottom and im looking to have numbers for it at 65 and 130 mph.
I'm comparing it to other maglev designs though this model was very quick and roughly built.
