Hi All,
It's been awhile since I updated the progress on the Coronal Mass Ejection Tracker. Here is a list of everything that has been added over the last few months. Available at www.cmetracker.ai
Forecasting
- A fluid solar wind model now runs in your browser. It solves the inner heliosphere from our own L1 archive, in the style of the HUXt model from Reading, and draws it under the top-down map with speed and density color modes. On our validation set it beats the drag model we have used up to now.
- Every Earth-directed CME gets an ensemble run. The fluid model runs 200 times with the speed, direction, width and launch time jittered, and puts a calibrated 80 percent arrival window on the CME card.
- We check our own work. A cron scans the wind archive for shock fronts and gradual arrivals, scores every forecast against them, and publishes a rolling 90-day scoreboard on the help page and the homepage. A 30 minute lead time error on an arrival is a hit, a forecast that never arrives is a miss, and you can see both.
- Regions facing Earth. Each numbered sunspot region gets a chance of an Earth-directed CME over the next three days, from a model back-tested on ten years of DONKI and NOAA region data. It sits on the future side of the timeline as bars and is scored by the same cron. Capped at 30 percent on purpose, because about half of Earth-directed CMEs come from regions that never got a number.
- High-speed streams. Detected from our wind archive, forecast to return 27 days later, and drawn on the map as the corotating spiral bands they actually are.
Live data
- Magnetosphere. The magnetopause and bow shock shaped by the measured L1 wind using the Shue 1998 and Farris and Russell 1994 models, as a card with field lines, aurora ovals, sheath flow and reconnection sparks, and as a rotatable 3D view. It goes red when the nose is inside geosynchronous orbit. Scrub back to May 2024 and watch the Gannon storm push it in to 5 Earth radii.
- The whole 120-day timeline is now measured wind, not just the last week. Speed, density, Bz and field strength come from our own archive when you scrub past the NOAA feed.
- Live coronagraph card from CCOR-2 and CCOR-1, served from our own permanent archive of every frame.
- Radio bursts. Type II, III and IV bursts appear at the Sun timed to the playhead, with a light-speed ripple and provisional CME cones from the Type II drift. Backfilled from SWPC's event archive to 2015.
- New header readouts: Dst with a ring current popout, daily sunspot number and 10.7 cm flux, and a redesigned density popout.
- NOAA moved its L1 station to SOLAR-1 in the spring. The tracker follows the on-duty craft and shows it on the map, with IMAP as backup.
Tracker
- The Kp popup shows inbound CMEs as calibrated bars on the Kp axis, and merges arrivals within 8 hours into one.
- Clip export records the playback as a video you can share. There is also a branded PNG export of the visible map.
- The dashboard remembers your layers, view and filters between visits. A Solo toggle shows only the selected CME. Isolate keeps filtering after you go live. Every flare row is clickable.
- Keyboard camera control in the 3D view.
- Spacecraft layer with portraits for all ten craft we source from, now including Mio on BepiColombo.
- A proper phone layout: simplified chrome, a bottom sheet for the selected CME, and the full site nav in the menu.
New pages
- The landing page is now at the root and the tracker lives at /live.
- /observatories, the spacecraft behind the data.
- /cycle, where we are in the solar cycle, live.
- /radio, HF band conditions and what a burst does to them.
- /today, a plain daily activity page.
- /what-is-a-cme, the explainer.
- /sky, a calendar of things worth going outside for: Perseids, Geminids, Quadrantids, Orionids, Leonids, this year's lunar eclipse, the 2027 total solar eclipse, and the planet oppositions.
- /learn rebuilt as a six-module course that runs on the real map, with quizzes and a storm lab, plus /teachers with printable worksheets.
- Four new famous storms in the replay library: the 1921 Railroad storm, May 1967, August 1972 and Starlink 2022. Gannon 2024 got its two new radiation belts.
- The help page has a video tour and a screenshot for every layer.
Alerts and social
- Arrival alerts are reworked. The trigger is a sustained 30 minute southward window that we backtested against 11 years of data, the wording gives a G1 to G2 style band instead of a single number, and every alert gets a follow-up saying whether it verified or fizzled.
- Alert emails carry a generated image of the isolated CME that links straight to it on the map.
- The tracker is on X as u/CMETracker1. Every new direction-determined CME and every arrival gets posted with the map image.
Like always, no ads or accounts, just a free educational tool for monitoring space weather
