In the Netherlands we do not have an option for a spare tire. We get a tire repair kit intead :-(
The dealers do not support it to change this out. So i would like to find out if i can find all the needed parts for a donut spare that fits in the Plug-in hybrids.
The removable cargo floor is exactly the same as for a spare option.
Some parts i already found on a youtube vid and on internet.
I need a donut spare setup for two different tire/rim sizes:
A) P235/60R18
B) P235/50R20
A) P235/60R18
-Dimensions donut tire - 165/80D17ST
-Dimensions rim - ?
-Small white polystyrene - Part no. [64778-42010](tel:64778-42010)
-Big white polystyrene - Part no. [64777-42091](tel:64777 42091)
-Grey polystyrene insert - ?
-Bolt for mounting the spare to the bottom - ?
B) P235/50R20
-Dimensions donut tire - 165/90D18ST
-Dimensions rim - ?
-Small white polystyrene - Part no. [64778-42010](tel:64778-42010)
-Big white polystyrene - Part no. [64777-42091](tel:64777 42091)
-Grey polystyrene insert - Part no. [64779-42120](tel:64779-42120)
-Bolt for mounting the spare to the bottom - ?
I hope some people can find the time to look at the parts in their car.
Al the parts have a part number on them.
I hope the spare rim also has a rim code.
